2019 - 2022 Projects

Project Description:

The Reconstruction of Samuel Adedoyin is approximately 200m Road length with varied 15.0m – 16.0m Right of way.

The Reconstruction included extensive earthworks, Provision of a Crushed Stone Base and Interlocking Paving Blocks Finish to the 11.0m Single Carriageway wide with provision of Parking Spacing on both sides. The Drainage has an internal dimension of 1.2m wide by (1.0m – 1.2m) depth on both sides of the Roadway, with the top serving as Pedestrian Walkway.

There are provision of 2No service duct crosses the Road at two (2No) locations for utilities works, as well as provision of 14No (Solar Powered) Street light at 30m interval at both sides of the Roadway.

Project Description:

The Reconstruction of Magbon Close is approximately 175m Road length with varied of between Right of way, of 10.0m – 12.0m.

The Reconstruction included extensive earthworks, Provision of a Crushed Stone Base and Interlocking Paving Blocks Finish to the 7.2m wide Carriageway. The drainage has an internal dimension of 0.9m wide by 0.7m depth on both sides of the road with drain top slab serving as walkway.

There are provision of 12No (Solar Powered) street light at 30m interval on both sides and a provision of 2No – 150mm uPVC sleeves along the Road side on both sides for utilities works.

Project Description:

ANOH Gas Processing Company is a Gas Processing Company which Expanded and Developed their Field Base Buildings and Facilities. Our main Task was to produce Structural Engineering Detailed Designs and Drawings for the highlighted ForwardBase Facilities;

FLB 01 – FLB Restaurant, Office & Clinic Building

FLB 02 – Lounge Building

FLB 03 – Gym. & Communal Shower Building

FLB 04 – Facility Manager's Office Building

FLB 05 – Residential Blocks–Standard, 13 no.

FLB 06 – Residential Block–Executive, 1 no.

FLB 07 – Laundry Building

FLB 08 – Lawn Tennis Court (2 No.)

FLB 09 – Five–a–Side Football Pitch

FLB 10 – Basketball Court

FLB 11 – Skip Block

FLB 12 – Electrical / IT Services Building

Military Unit Caravans

PA 01 – Inplant Admin. Building

PA 02 – Warehouse

PA 03 – Workshop Building

PA 04 – Chemical Storage Shed

PA 07 – Fire Station Building

PA 08 – Truck Loading Admin. Building

PA 09 – Drivers Rest Room–Lounge

PA 10A-B – FLB Access, LPG Area Entrance & Exit, and Plant Area Gate Houses
Covered Walkway
